Introduction
This cryogenic liquid cylinder automatic welding equipment uses plasma welding machine+TIG welding machine, automatic wire feeder, and visual laser dual tracking system. This solution adds a set of visual laser automatic dual tracking system (used for automatic tracking of welds, using visual imaging technology for real-time tracking, guiding the welding gun to automatically align the weld to ensure weld quality. The system is equipped with a German industrial PC, high-speed camera, industrial computer display, and a two-dimensional actuator driven by a servo motor + precision ball screw). Automatically align and track the weld.
Product Details
Product Name:Cryogenic Liquid Cylinder Longitudinal Welding Machine(Plasma and TIG Welding)
1) Weldable material: SUS304
2) Diameter range: ￠400mm～￠900mm
3) Welding length: 2000mm
4) Workpiece thickness: 4mm～6mm
5) Plasma welding+TIG welding
Product advantage
This Cryogenic Storage Tank Longitudinal Welder equipment is based on the longitudinal seam plasma automatic welding equipment and adds a TIG welding head for weld base welding. Adding an oscillator to the TIG welding head can make the weld fuller.
This Cryogenic Cylinder Longitudinal Welding Machine has the following advantages:
1) On 2.5-10mm plates, it can achieve no beveling, one-time penetration, single-sided welding and double-sided forming.
2) Use TIG to cover the surface to make the front weld beautiful and smooth, which is convenient for subsequent polishing.
Why choose us
QINENG welding professionally develops Cryogenic Liquid Cylinder Welding Machine, with an annual output of up to 1 million cylinders, truly providing cost-reduction and efficiency-enhancing solutions for cylinder manufacturing companies!
In order to better serve our customers, we continue to invest in the research and development of LPG Cylinder Welding Machine products and optimize the production process!
